DWC-MV72Di28T

MEGApix 2.1MP/1080p ultra low-profile vandal dome IP camera with fixed lens and IR
Find a Reseller Request a Demo Contact Us FAQs
Features
  • 2.1MP/1080p 1/2.9" image sensor at real-time 30fps
  • 2.8mm fixed lens
  • Digital Wide Dynamic Range (D-WDR)
  • Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
  • 80' Smart IR™ with intelligent camera sync
  • Ultra low-profile vandal dome camera housing
  • Smart DNR™ 3D digital noise reduction
  • True day/night mechanical IR cut filter
  • Programmable privacy zones
  • Auto gain control (AGC)
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
  • Motion detection
  • Web server built-in
  • PoE class 2 and DC12V
  • Waterproof cabling
  • UL listed
    • Show More

Learn about how DW
solutions can work for you

View All Markets

Ultra Low-Profile Vandal Dome Housing

The micro dome cameras are small and discrete, ideal for high-end applications where the cameras integrate into the overall design. HD video surveillance in a small and sleek design allows for discrete installations.

Megapixel resolution

DW’s technology delivers crystal clear images in any resolution. Higher-resolution offers forensic details with zooming into the camera’s field of view.

Decorative rings

Customize your ultra low-profile vandal domes with decorative rings. The DWC-V7DECO set of five (5) white rings can be painted to match your décor.

Specifications

Image sensor 2.1MP/1080p 1/2.9" CMOS sensor
Maximum resolution 2.1MP/1080p
Minimum Scene Illumination in color 0.0 lux (B/W), 0.16 lux (color)
Lens
Horizontal Field of View (HFOV) 109°
IR Distance 80' range Smart IR™
Lens Type Fixed Lens
Vertical Field of View (VFOV) 53.2°
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Auto day/night, Day (color), Night (B/W)
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Email, FTP server, SD card recording
Sharpness Yes
White Balance Yes
Network
Network Web Viewer Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol Zeroconf (AutoIP)
Security 802.1x, Digest authemtication (ID/PW), HTTPS (TLS), IP filtering
Video Compression Type H.264, H.265, MJPEG
Video Management Software Any ONVIF conformant CMS, DW Spectrum® IPVMS
Environmental
Compliance CE  FCC  NDAA Compliance  ONVIF  RoHS, UL Listing
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Housing Vandal Dome
Housing Color Ivory
IK rating IK10 Rated
IP rating Weather Resistant (IP67)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) Cable type #18
Power Requirements (Adapter not included), IEEE 802.3af Class 2, PoE
General
Warranty 5 Year Warranty
