Home IP Cameras DWC-PVF9Di2TW, DWC-PPVF9Di2TW

DWC-PVF9Di2TW
DWC-PPVF9Di2TW

MEGApix IVA 9MP fisheye IP camera with fisheye lens, IR and IVA
Find a Reseller Request a Demo Contact Us FAQs
NDAA
Features
  • 9MP 1/1.7 image Sensor at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology
  • Intelligent Video Analytics (IVA pre-loaded models)
  • Extended Intelligent Video Analytics (IVA+ pre-loaded models)
  • Seamless integration and control of IVA rules with DW Spectrum® IPVMS
  • Reduce false alarms
  • Increase your recording storage with logic rules and smart recording
  • Support 360° hemispheric fisheye view and 360°, 180° and 90° panoramic view
  • Edge-to-edge image clarity
  • 2.1mm fisheye lens
  • Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
  • 360° 80' Smart IR™ with intelligent camera sync.
  • Smart DNR™ 3D digital noise reduction
  • True day/night with mechanical IR cut filter
  • Auto gain control (AGC)
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
    • Show More

IVA Analytics

MEGApix IVA cameras have a powerful engine to detect and classify people and vehicles in real-time. IVA+ license upgrade offers advanced video content analysis detection capabilities.

LEARN MORE

IVA integrates seamlessly with DW Spectrum® IPVMS

MEGApix IVA analytics are seamlessly integrated with DW Spectrum IPVMS for easy configuration, real-time alerts and automatic notifications.
Learn more.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

360° hemispheric and panoramic fisheye views at real-time 30fps

360° fisheye view IP cameras MEGApix® Pano™ 360° view fisheye cameras with IR monitor an entire room with a single camera, providing the ultimate ROI.

Smart IR™

Smart IR™ adjusts the image for IR cameras to prevent excessive illumination on objects that are in the front of the scene and offers a clear image in B/W without any loss of detail.

Megapixel resolution

DW’s technology delivers crystal clear images in any resolution. Higher-resolution offers forensic details with zooming into the camera’s field of view.

Specifications

Active Pixels 3008 (H) X 3000 (V)
Image sensor 12.4MP 1/1.7” CMOS
Maximum resolution 9MP
Minimum Scene Illumination in color 0.03 lux (color), 0.0 lux (B/W)
Total Pixels 3096 (H) X 2080 (V)
Lens
Focal Length 2.1mm
Horizontal Field of View (HFOV) 185°
IR Distance 80' range Smart IR™
Lens Type Fixed Lens
Vertical Field of View (VFOV) 185°
I/O
Audio compression G.711
I/O Alarm in/out 1 input, 1 output
I/O Audio in/out 1 input (1.0Vms, 3K ohm)
Intelligent Video Analytics
IVA license Intrusion, line crossing, counting line, loitering, enter, exit, tamper
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Backlight compensation (BLC) Yes
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Memory slot Micro SD/SDHC/SDXC class 10 card (card not included), Upto 1TB micro SD / exFAT
Mirror/flip Yes
Motion Detection Yes
Operational features Star-Light Plus, True D/N
Operational Notifications Email, FTP server, Alarm output activation, SD card recording
Privacy Zones 16 programmable privacy masks
Shutter Mode Auto, Manual, Slow Shutter, Anti-Flicker
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off, x2, x3, x5, x6, x7.5, x10
Wide Dynamic Range (WDR) D-WDR
Network
Bitrate Control Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
IP IPv4
LAN RJ45 (10/100Base-T)
Network resolution H.265: 3008x3000, 2800x2800, 2048x2048, 1600x1600, 640x640, 320x320, H.264: 3008x3000, 2800x2800, 2048x2048, 1600x1600, 640x640, 320x320, MJPEG: 1280x1280, 640x640, 320x320
Network Web Viewer Windows® OS, Mac® OS, Linux® OS, Internet Explorer® browser, Google Chrome® browser, Mozilla Firefox® browser, Safari® browser
Protocol Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, ICMP, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security HTTPS (TLS), MAC filtering, 802.1x, Multi-user authority
Stream Speed Up to 30fps at all resolutions
Streaming Capability Dual-stream at different rates and resolutions
Video Bitrate 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type H.264, H.265, MJPEG
Video Management Software DW Spectrum® IPVMS
Environmental
Compliance NDAA Compliance, UL Listing  CE, FCC, RoHS, ONVIF
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) 4.66" x 3.58" (118.6 x 91 mm), 4.92" x 1.88” (125 x 48 mm)
Housing Fisheye
IK rating IK09 Rated
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Weight 1.10 lbs (0.5kg)
Electrical
Power Consumption DC12V: max 8.5W, 708.3mA, PoE: max 10.0W
Power Requirements PoE, IEEE 802.3af Class 3, (Adapter not included), 12V DC
General
Warranty 5 Year Warranty

Part Numbers

Part Number Description
DWC-PVF9Di2TW preloaded with IVA.
DWC-PPVF9Di2TW preloaded withIVA+.

Accessories

DWC-VFHMW
Hanging mount for selected vandal dome and fisheye cameras
Learn more
DWC-VFCMW
Ceiling mount bracket for selected vandal dome and turret cameras
Learn more
DWC-GPLT-W
Converter plate for electronic gang box
Learn more
DWC-V1CNMW
Corner and pole mount bracket
Learn more
DWC-VFJUNCW
Junction box for selected vandal dome and turret cameras
Learn more
DWC-WMJUNCW
Junction box for wall mount brackets
Learn more
DWC-PMB-WLW
Pole mount bracket
Learn more
DWC-VFWMW
Wall mount bracket for selected vandal dome and turret cameras
Learn more
